Item Description
New construction housing for use in insulated ceilings can be in direct contact with insulation. Air-tight construction provides energy savings by reducing the flow of air through the ceiling. Patented design allows for easy, tool-less removal of the driver. Input Voltage: 120/277V Wattage: 20W Dimming: Phase (Triac or ELV) or 0-10V Ceiling Thickness: Up to 0.5in. Extension collar accessory for ceilings up to 2", ordered separately (NIO-4EXTC2) Compatible Trims: NIO-4PSTLA, NIO-4PSTLNDC Listing: cULus Listed for Damp Locations (Wet locations when used with compatible trim)

• Item ID: 1HV2GL
• Width: 1.75
• Height: 5.75
• Finish: Unfinished
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 9
• Length: 17.125
• Ship Carton Height: 9
• Ship Carton Length: 17
• Ship Carton Width: 14
• Weight: 6
• 8
• Contains Battery: N
• Country of Origin: CHN
• DLC Listed: No
• Master Box H: 13
• Master Box L: 22
• Master Box Qty: 4
• Master Box W: 21
• Master Box Wt.: 26
• Product Family: 4" Iolite Dedicated Housing
• Safety Listing: cULus
• Wattage: 20W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Recessed Housing New
• Standard Finish: Miscellaneous

Item Description
4" PLUS Trimless Iolite downlights have no exposed flange and do not extend beyond the ceiling plane. Iolite PLUS Trimless requires a PLUS Trimless Mud Ring and New Construction housing. Deep regressed cone reflector optimizes visual cut-off and adjust up to 35°. Required Trimless Mud Plate: NIO-TLMR-4PR Compatible Housing: NHIOICD-4PS15, NHIOICD-4PS20, NHIOICDCP-4PS15, NHIOICDCP-4PS20 Lumens / Wattage: Up to 2000lm / 24W (varies by housing) Color Temperature: 5000K Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Listing: cULus listed for damp locations Accessories: NIO-AS, NIO-HC

• Item ID: 1HXVC5
• Width: 3.50
• Height: 4.50
• Finish: Matte Powder White
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 2
• Length: 3.5
• Lumens / Light Output: 1500lm or 2000lm (varies by housing)
• Ship Carton Height: 3.375
• Ship Carton Length: 9.75
• Ship Carton Width: 4
• Weight: 1
• 1.3
• CCT: 5000K
• CEC Database: Y
• CEC Item Number: NIO-4********
• CEC Substitute Item: NIO-4PSTLNDC27XMPW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 15
• Master Box L: 21
• Master Box Qty: 24
• Master Box W: 13
• Master Box Wt.: 34
• Product Family: 4" Iolite Dedicated Trimless
• Safety Listing: cULus
• Wattage: 20W or 24W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
4" PLUS Trimless Iolite downlights have no exposed flange and do not extend beyond the ceiling plane. Iolite PLUS Trimless requires a PLUS Trimless Mud Ring and New Construction housing. Deep regressed cone reflector optimizes visual cut-off. Required Trimless Mud Plate: NIO-TLMR-4PR Compatible Housing: NHIOICD-4PS15, NHIOICD-4PS20, NHIOICD-4PS25, NHIOICDCP-4PS15, NHIOICDCP-4PS20, NHIOICDCP-4PS25 Lumens / Wattage: Up to 2500lm / 28W (varies by housing) Color Temperature: 3000K Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: White Listing: cULus listed for wet locations Accessories: NIO-AS, NIO-HC

• Item ID: 1HXVCK
• Width: 3.50
• Height: 4.13
• Finish: White
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 2
• Length: 3.5
• Lumens / Light Output: 1500lm / 2000lm / 2500lm (varies by housing)
• Ship Carton Height: 3.375
• Ship Carton Length: 9.75
• Ship Carton Width: 4
• Weight: .85
• 1.15
• CCT: 3000K
• CEC Database: Y
• CEC Item Number: NIO-4********
• CEC Substitute Item: NIO-4PSTLNDC35XWW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 15
• Master Box L: 21
• Master Box Qty: 24
• Master Box W: 13
• Master Box Wt.: 31
• Product Family: 4" Iolite Dedicated Trimless
• Safety Listing: cULus
• Wattage: 20W / 24W / 28W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
2" Iolite LED downlights require a dedicated Iolite new construction housing. Bullnose with a filleted aperture which allows for minimal aperture brightness while still producing the nadir footcandles. Compatible Housing: NHIOICD-215, NHIOICD-220, NHIOICD-225, NHIOICDCP-215, NHIOICDCP-220, NHIOICDCP-225 Lumens / Wattage: Up to 2500lm / 28W (varies by housing) Color Temperature: Comfort Dim (3000K-2000K) Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Listing: cULus listed for wet locations Accessories: NIO-AS, NIO-HC, NIO-FMMR-2S

• Item ID: 1U5Z02
• Width:
• Height:
• Finish: Matte Powder White
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 2
• Lumens / Light Output: 1500lm / 2000lm / 2500lm (varies by housing)
• Ship Carton Height: 3.5
• Ship Carton Length: 9
• Ship Carton Width: 6
• 1.1
• CCT: Comfort Dim (3000K-2000K)
• CEC Database: Y
• CEC Item Number: NIOB-2********
• CEC Substitute Item: NIOB-2SNB40XMPW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 12
• Master Box L: 19
• Master Box Qty: 12
• Master Box W: 13
• Master Box Wt.: 15
• Product Family: 2" Iolite Dedicated Trim
• Safety Listing: cULus
• Wattage: 20W / 24W / 28W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
2" Iolite LED downlights require a dedicated Iolite new construction housing. Deep regressed cone reflectors optimize visual cut-off. Compatible Housing: NHIOICD-215, NHIOICD-220, NHIOICD-225, NHIOICDCP-215, NHIOICDCP-220, NHIOICDCP-225 Lumens / Wattage: Up to 2500lm / 28W (varies by housing) Color Temperature: Comfort Dim (3000K-2000K) Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Reflector / Matte Powder White Flange Listing: cULus listed for wet locations Accessories: NIO-AS, NIO-HC, NIO-FMMR-2S

• Item ID: 1U5ZWH
• Width:
• Height:
• Finish: Matte Powder White Reflector / Matte Powder White Flange
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 2
• Lumens / Light Output: 1500lm / 2000lm / 2500lm (varies by housing)
• Ship Carton Height: 3.5
• Ship Carton Length: 9
• Ship Carton Width: 6
• 1.1
• CCT: Comfort Dim (3000K-2000K)
• CEC Database: Y
• CEC Item Number: NIOB-2********
• CEC Substitute Item: NIOB-2SNDC40XMPW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 12
• Master Box L: 19
• Master Box Qty: 12
• Master Box W: 13
• Master Box Wt.: 15
• Product Family: 2" Iolite Dedicated Trim
• Safety Listing: cULus
• Wattage: 20W / 24W / 28W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
4" Iolite LED downlights require a dedicated Iolite new construction housing. Die-cast adjustable reflectors optimize visual cut-off and adjustable to aim the light source in desired direction. Adjustability: 40° Compatible Housing: NHIOICD-415, NHIOICD-420, NHIOICDCP-415, NHIOICDCP-420 Lumens / Wattage: Up to 2000lm / 24W (varies by housing) Color Temperature: Comfort Dim (3000K-2000K) Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Reflector / Matte Powder White Flange Listing: cULus listed for damp locations Accessories: NIO-AS, NIO-HC, NIO-FMMR-4R

• Item ID: 1U5XYK
• Width:
• Height:
• Finish: Matte Powder White Reflector / Matte Powder White Flange
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 3
• Lumens / Light Output: 1500lm or 2000lm (varies by housing)
• Ship Carton Height: 3.5
• Ship Carton Length: 9
• Ship Carton Width: 6
• 1.35
• CCT: Comfort Dim (3000K-2000K)
• CEC Database: Y
• CEC Item Number: NIO-4********
• CEC Substitute Item: NIO-4RD50XBB/10
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 12
• Master Box L: 19
• Master Box Qty: 12
• Master Box W: 13
• Master Box Wt.: 17
• Product Family: 4" Iolite Dedicated Trim
• Safety Listing: cULus
• Wattage: 20W or 24W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
4" Iolite LED downlights require a dedicated Iolite new construction housing. Adjustable slot aperture focuses the beam spread through 2-5/8" x 2" opening. Adjustability: 25° Compatible Housing: NHIOICD-415, NHIOICD-420, NHIOICD-425, NHIOICDCP-415, NHIOICDCP-420, NHIOICDCP-425 Lumens / Wattage: Up to 2500lm / 28W (varies by housing) Color Temperature: Comfort Dim (3000K-2000K) Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Aperture / Matte Powder White Flange Listing: cULus listed for damp locations Accessories: NIO-AS, NIO-HC, NIO-FMMR-4R

• Item ID: 1U5XZN
• Width:
• Height:
• Finish: Matte Powder White Slot Aperture / Matte Powder White Flange
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 3
• Lumens / Light Output: 1500lm / 2000lm / 2500lm (varies by housing)
• Ship Carton Height: 3.5
• Ship Carton Length: 9
• Ship Carton Width: 6
• 1.4
• CCT: 5000K
• CEC Database: Y
• CEC Item Number: NIO-4********
• CEC Substitute Item: NIO-4RSL40XMPW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 12
• Master Box L: 19
• Master Box Qty: 12
• Master Box W: 13
• Master Box Wt.: 18
• Product Family: 4" Iolite Dedicated Trim
• Safety Listing: cULus
• Wattage: 20W / 24W / 28W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
2" Iolite LED downlights require a dedicated Iolite new construction housing. Adjustable slot aperture focuses the beam spread through 1-3/4" x 1-3/8" opening. Adjustability: 30° Compatible Housing: NHIOICD-215, NHIOICD-220, NHIOICD-225, NHIOICDCP-215, NHIOICDCP-220, NHIOICDCP-225 Lumens / Wattage: Up to 2500lm / 28W (varies by housing) Color Temperature: Comfort Dim (3000K-2000K) Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Aperture / Matte Powder White Flange Listing: cULus listed for damp locations Accessories: NIO-AS, NIO-HC, NIO-FMMR-2R

• Item ID: 1U5YZP
• Width:
• Height:
• Finish: Matte Powder White Slot Aperture / Matte Powder White Flange
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 2
• Lumens / Light Output: 1500lm / 2000lm / 2500lm (varies by housing)
• Ship Carton Height: 3.5
• Ship Carton Length: 9
• Ship Carton Width: 6
• 1.1
• CCT: Comfort Dim (3000K-2000K)
• CEC Database: Y
• CEC Item Number: NIOB-2********
• CEC Substitute Item: NIOB-2RSL40XMPW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 12
• Master Box L: 19
• Master Box Qty: 12
• Master Box W: 13
• Master Box Wt.: 15
• Product Family: 2" Iolite Dedicated Trim
• Safety Listing: cULus
• Wattage: 20W / 24W / 28W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
2" Iolite LED downlights require a dedicated Iolite new construction housing. Deep regressed cone reflectors optimize visual cut-off. Compatible Housing: NHIOICD-215, NHIOICD-220, NHIOICD-225, NHIOICDCP-215, NHIOICDCP-220, NHIOICDCP-225 Lumens / Wattage: Up to 2500lm / 28W (varies by housing) Color Temperature: Comfort Dim (3000K-2000K) Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Reflector / Matte Powder White Flange Listing: cULus listed for wet locations Accessories: NIO-AS, NIO-HC, NIO-FMMR-2S

• Item ID: 1U5ZWT
• Width:
• Height:
• Finish: Matte Powder White Reflector / Matte Powder White Flange
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 2
• Lumens / Light Output: 1500lm / 2000lm / 2500lm (varies by housing)
• Ship Carton Height: 3.5
• Ship Carton Length: 9
• Ship Carton Width: 6
• 1.1
• CCT: Comfort Dim (3000K-2000K)
• CEC Database: Y
• CEC Item Number: NIOB-2********
• CEC Substitute Item: NIOB-2SNDSQ40XMPW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 12
• Master Box L: 19
• Master Box Qty: 12
• Master Box W: 13
• Master Box Wt.: 15
• Product Family: 2" Iolite Dedicated Trim
• Safety Listing: cULus
• Wattage: 20W / 24W / 28W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24

Item Description
4" Iolite LED downlights require a dedicated Iolite new construction housing. Adjustable pinhole focuses the beam spread through small opening. Adjustability: 30° Compatible Housing: NHIOICD-415, NHIOICD-420, NHIOICD-425, NHIOICDCP-415, NHIOICDCP-420, NHIOICDCP-425 Lumens / Wattage: Up to 2500lm / 28W (varies by housing) Color Temperature: Comfort Dim (3000K-2000K) Color Rendering Index: 90 CRI Beam Spread: Three field changeable optics included Finish: Matte Powder White Pinhole / Matte Powder White Flange Listing: cULus listed for damp locations Accessories: NIO-AS, NIO-HC, NIO-FMMR-4R

• Item ID: 1U5XZD
• Width:
• Height:
• Finish: Matte Powder White Pinhole / Matte Powder White Flange
• Category: Recessed
• Product Line: LE46
• Est. Shipping Wt.: 3
• Lumens / Light Output: 1500lm / 2000lm / 2500lm (varies by housing)
• Ship Carton Height: 3.5
• Ship Carton Length: 9
• Ship Carton Width: 6
• 1.4
• CCT: Comfort Dim (3000K-2000K)
• CEC Database: Y
• CEC Item Number: NIO-4********
• CEC Substitute Item: NIO-4RPHCDXMPW/HL
• Contains Battery: N
• Country of Origin: CHN
• CRI: 90
• DLC Listed: No
• Master Box H: 12
• Master Box L: 19
• Master Box Qty: 12
• Master Box W: 13
• Master Box Wt.: 18
• Product Family: 4" Iolite Dedicated Trim
• Safety Listing: cULus
• Wattage: 20W / 24W / 28W
• Standard Category: Recessed Ltg.
• Standard Subcategory: Other Recessed Ltg.
• Standard Option: Title 24
